Hydraulic punching machines are industrial machines used for punching metal sheets, pipes and other plate sheets. These machines perform the drilling process by generating high pressure through hydraulic systems. As SBFM Makine, there is a “Flanging Machines (Without Center Hole)” available in our current product profile. But for those who are curious about “hydraulic drilling machines with holes”, we will give a detailed review of how “hydraulic drilling machines” work.

Fundamentals of Hydraulic System

Hydraulic systems perform mechanical operations using liquid pressure. In hydraulic drilling machines, the hydraulic fluid (usually machine oil) is compressed to a high pressure by means of a pump and this pressure is transferred to a piston or cylinder. This pressurized liquid moves the piston, and this movement is delivered to the drilling head, which provides the drilling process.

The Main Components

1. Hydraulic Pump: It delivers the hydraulic fluid in the system to the high pressure point. It can be powered by electric motor or internal combustion engine.

2. Hydraulic Cylinder: By taking the pressurized liquid produced by the pump, the piston provides its movement.

3. Piston: It performs mechanical works by moving under the influence of pressurized liquid. At this stage, it pushes the drilling head downwards.

4. Drilling Head: It performs the drilling process by transmitting the movement of the piston to the work section.

5. Control Valves: It provides pressure and directional controls by regulating the liquid flow.

6. Oil Tank: Stores and recycles the hydraulic fluid of the system.

Working Principle

1. Starting: When the machine is started, the hydraulic pump compresses the hydraulic fluid between the high pressure.Dec.

2. Pressurized Liquid Flow: The pressurized liquid is transferred to the hydraulic cylinder with the help of pipes.

3. Piston Movement: Every time the pressurized liquid pushes the piston down in the cylinder, this movement generates a large force.

4. Drilling Process: The movement of the piston pushes the drilling head towards the metal material. The drilling head performs the process of drilling holes into the metal sheet plate.

5. Return: When the process is finished, the control valves change the direction of the liquid and the piston makes its upward movement. This movement allows the drilling head to return to the starting point.

6. Return of the Liquid: The hydraulic fluid used during the process returns to the oil tank and the cycle continues as it first started.

Advantages and Application Areas

Hydraulic drilling machines are useful for metal drilling operations that require high strength and precision. It is used in many industries such as metal processing, automotive, construction and manufacturing. The advantages include high power, durability, low maintenance requirements and user-friendly control systems. Dec.

Result

Hydraulic drilling machines perform the task of effective and efficient drilling operations by using the power of hydraulic systems. The use of high-pressure hydraulic fluid helps these machines to perform high-efficiency even in heavy work. The synchronized operation of many machine components allows these machines to play an important role in industrial production.

As SBFM makine, in this article, we have made a detailed review about the working principles and components of hydraulic drilling machines. In the current product profile of SBFM MAKINE, there are non-perforated versions of these machines. In addition, you can contact our experts to learn more about our many machines such as machines working with hydraulic systems, hydraulic cylinder bending machines, press machines and to explore the industrial applications of these machines, or you can visit our products department and examine the machines you want.
